Cable solaris 62930 IEC131 compatitur cum componentibus maxime photovoltaicis usque ad 1500 V DC aestimatis, inter pixides coniunctas PV et connexiones PV tuta, stabilis et efficax transmissio in amplis institutionibus PV praestandi.
62930 IEC 131
1 ** mm²
1500 V DC
Halogen-liber · Low fumus
TYKJ
1.4 mm² Solar PV Cable
Supplevimus in rotulis 100-metris, cum 112 rotulis per grabatis, vel in 500-metris, cum 18 rotulis per grabatis.
2.Container Loading
Vexillum continens viginti pedum usque ad viginti grabatis accommodare potest, global navigium efficiens.
3.Flexible Options
Consuetudo voluminis longitudines, cables magnitudinum, et figurarum grabatum praesto sunt in petitione ad obviam project requisita.
| Item No. | Productum Nomen | Exemplar | Ratum Voltage | Conductorcrucis sectione mm 2 | Strand design Numerus x Ø mm | Conductor resistentia Ω / km 20°C | Exterior-Ømm | Vagina Color |
|---|---|---|---|---|---|---|---|---|
| PV-131-15B . | PV Cable | 131 | 1500VDC | 1X1.5 | 30/0.25 | 13.70 | 4.7±0.1mm | Niger |
| PV-131-15R | PV Cable | 131 | 1500VDC | 1X1.5 | 30/0.25 | 13.70 | 4.7±0.1mm | Red |
| PV-131-25B | PV Cable | 131 | 1500VDC | 1X2.5 | 49/0.25 | 8.21 | 5.3±0.1mm | Niger |
| PV-131-25R | PV Cable | 131 | 1500VDC | 1X2.5 | 49/0.25 | 8.21 | 5.3±0.1mm | Red |
| PV-131-40B | PV Cable | 131 | 1500VDC | 1X4.0 | 56/0.285 | 5.09 | 5.6±0.1mm | Niger |
| PV-131-40R | PV Cable | 131 | 1500VDC | 1X4.0 | 56/0.285 | 5.09 | 5.6±0.1mm | Red |
| PV-131-60B | PV Cable | 131 | 1500VDC | 1X6,0 | 84/0.285 | 3.39 | 6.1±0.1mm | Niger |
| PV-131-60R | PV Cable | 131 | 1500VDC | 1X6.0 | 84/0.285 | 3.39 | 6.1±0.1mm | Red |
| PV-131-100B | PV Cable | 131 | 1500VDC | 1X10 | 77/0.4 | 1.95 | 7.3±0.1mm | Niger |
| PV-131-100R | PV Cable | 131 | 1500VDC | 1X10 | 77/0.4 | 1.95 | 7.3±0.1mm | Red |
| PV-131-160B | PV Cable | 131 | 1500VDC | 1X16 | 126/0.4 | 1.24 | 9.3±0.1mm | Niger |
| PV-131-160R | PV Cable | 131 | 1500VDC | 1X16 | 126/0.4 | 1.24 | 9.3±0.1mm | Red |
| PV-131-250B | PV Cable | 131 | 1500VDC | 1X25 | 196/0.4 | 0.795 | 11.2±0.1mm | Niger |
| PV-131-250R | PV Cable | 131 | 1500VDC | 1X25 | 196/0.4 | 0.795 | 11.2±0.1mm | Red |
| PV-131-350B | PV Cable | 131 | 1500VDC | 1X35 | 273/0.4 | 0.565 | 12.6±0.1mm | Niger |
| PV-131-350R | PV Cable | 131 | 1500VDC | 1X35 | 273/0.5 | 0.565 | 12.6±0.1mm | Red |
Conductor
Flexibile filum aeneum tinctum, obsecundans cum IEC 60228 Classis V, praestans conductivity, corrosio resistentiae, et durabilitas ad longum tempus PV systema faciendum.
Insulation
125°C fumus humilis, halogen-liberum polyolefin flammeum retardans, praebens resistentiam scelerisque superiorem, salutem electricam et tutelam environmental.
Exterior Vagina
Factus eiusdem 125°C fumus humilis, halogen-liberum polyolefin flammeum retardans, vires mechanicas procurans, UV resistentia, et effectus velit certa.
Processus specialis
Provectus electronica trabes annectens (E-trabem) technologiam auget velit stabilitatem, calorem tolerantiae, et altiore fune longitudinis.
| Cable design | |
|---|---|
| Conductor | Fila aenea tincta secundum IEC 60228, Classis 5 |
| Insulation | 125 Low-Fumum Halogen Free Flamma Retardant Polyolefins |
| Exteriore iaccam | 125℃ Halogen-Fumum Belgicum Flamma Retardant Polyolefins |
| Specialis technicae artis | Electron trabem crucis-connexum |
| Characteres electrica | |
| Ratumvoltage U0/U* | DC 1500V |
| Temperatus range | -40℃ usque ad +90℃ |
| Maximilianus. temperatus ad conductor | 120℃ |
| Min. inflexio radii | 5 x cable diameter |
| Signa industria | IEC62930: 2017 |
| Mensuratio resistentiae conductoris | IEC 60228:2004 |
| Mensuratio velit resistentia | IEC 60227-2:1997 |
| Voltage test in completo funem cum DC vel AC | IEC60245-2:1994 |
| Nulla diu terminus resistentiae DC ad | IEC62821-2:2015 |
| Ozone resistentia | IEC60881-506 |
| Tempestas / UV resistentiam | IEC62930: -Annex E |
| Test verticalis flammae propagationis in integrum funem | IEC60332-1-2 |
| Dimensiones et specificationes mutari possunt sine praevia notitia. | |
Cum X annis experientiae producentis Cable solaris 62930 IEC 131, Lorem in tradendo certas, altas quales PV funes et connexiones pro inceptis terrarum orbis.
Cotidiana productio capacitas nostra ad 200.000 metra funerum solaris ac 50,000 metrorum iungentium occidit, ut nos ordines tam parvos quam magnos efficienter occurrere possimus.
Omnes fructus nostri stricte producuntur in obsequio cum signis tam nationalibus quam internationalibus, cum unaquaque unitas probe probata antequam officinas relinquat.
TÜV, UL, CE certificationes consecuti sumus, omnesque relationes probationes pertinentes in petitione praesto sunt.
Libenter attingere si vis aliqua testimonialia vel documenta technica accipere.
Experientiam habemus X annorum in productione funalium PV et connexorum PV. Producere possumus 200,000 metra funerum PV ac 50,000 strophorum PV connexorum per diem producere. Nostrum grabatum de mensuris global venditionibus aptius est. Officina nostra non solum lineas productionis funis velocitatis habet, sed etiam instrumenta electronica irradiatio transversalis connexionis habet, quod instrumentum clavis est ad qualitatem funis regendam. Nostra technologia provectus praestat funibus producendis GENERALIS.
